Components

AV Equipment

• Laptops
• Projectors
• Speakers
• Clickers with Built-In Laser Pointers
• Cameras

LED Colors

• Red LED
• Blue LED
• White LED
• Orange LED
• Yellow LED
• Green LED
• 8 Segment LED
• 10 Segment LED

Potentiometers

• 100 Ω
• 500 Ω
• 1 KΩ
• 5 KΩ
• 10 KΩ
• 25 KΩ
• 50 KΩ
• 100 KΩ
• 500 KΩ
• 1 MΩ

PSoC Boards

• CY8CKIT-001 PSoC Development Kit
• CY3271 PSoC FirstTouch Starter Kit with Low Power RF
• CY8CKIT-003 PSoC 3 FirstTouch Starter Kit
• CY8CKIT-030 PSoC 3 Development Kit
• CY3210 PSoC 1 Evaluation Kit
• CY8CKIT-042 PSoC4 Pioneer Kit

Transistors

• 2N2222 (NPN Low Power BJT)
• 2N3904 (NPN General Purpose)
• 2N3906 (PNP General Purpose)
• 2N5459 (N-Channel JFET)
• 2N7000 (N-Channel MOSFET)
• PN2907A (PNP General Purpose BJT)
• TIP120 (NPN Epitaxial Darlington)
• TIP122 (NPN Epitaxial Darlington)
• TIP125 (PNP Epitaxial Darlington)

Zener Diodes/Diodes

• 1N4728 3.3V
• 1N4729 3.6V
• 1N4730 3.9V
• 1N4731 4.3V
• 1N4732 4.7V
• 1N4733 5.1V
• 1N4734A 5.6V
• 1N4735 6.2V
• 1N4736A 6.8V
• 1N4737 7.5V
• 1N4738 8.2V
• 1N4739 9.1V
• 1N4740 10V
• 1N4741 11V
• 1N4742 12V
• 1N4743 13V
• 1N4744 14V
• 1N5262B 51V
• Datasheet 1N4728 THRU 1N4764
• 1N5373
• 1N5401
• 1N4001
• 1N4006
• 1N4007
• 1N5817

Resistors

Please refer to the table above for resistor values

Integrated Circuits

• 1.2K Resistor Array
• 74HC590 (8-Bit Binary Counter with Output Register; 3-State)
• ADC0804 (8-Bit A/D Converter)
• CD4017 (Decade Counter with 10 Decoded Outputs)
• CD4026 (Decade Counter with 7 Decoded Outputs and Display Enable)
• CD4070 (Quadruple XOR)
• CD4543 (BCD-to-Seven Segment Latch/Decoder)
• CD40106 (Hex Schmitt Trigger)
• DAC0808 (8-Bit D/A Converter)
• DG413 (Quad SPST Analog Switch)
• DM7402 (Quadruple 2-Input NOR Gates)
• DM7404 (Hex Inverting Gates)
• DM7410 (Triple 3-Input NAND Gates)
• DM7432 (Quad 2-Input OR Gate)
• DM74240 (Octal 3-State Buffer/Line Driver/Line Receiver)
• ICL8038 (Precision Waveform Generator)
• LM317 (3-Terminal Adjustable Voltage Regulator)
• LM339 (Low Power, Low Offset Voltage Quad Comparators)
• LM380 (2.5W Audio Power Amplifier)
• LM384 (5W Audio Power Amplifier)
• LM386 (Low Voltage Audio Power Amplifier)
• LM555 Timer (Oscillation/Time Delay Generator)
• LM723 (Voltage Regulator)
• LM741 (Operational Amplifier)
• LM7805 (+5 Volt Regulator)
• M74HC112 (Dual J-K Flip Flop with Preset and Clear)
• SN7400 (Quadruple 2-Input Positive NAND)
• SN7408 (Quadruple 2-Input Positive AND)
• SN7414 (Hex Schmitt-Trigger Inverter)
• SN74151A (Data Selector/Multiplexer)
• SN7474 (Dual D-Type Positive-Edge-Triggered Flip-Flops with Present and Clear)
• SN74161 (Synchronous 4-Bit Counters)
• SN74HC86 (Quadruple 2-Input XOR)
• SN74LS93 (4-Bit Binary Counter)
• TLC080 (Family of Wide-Bandwidth High-Output-Drive Single Supply OP AMPS)

Capacitors

Please refer to the above table for capacitor values

Inductors

• 47 µH
• 560 µH
• 22 mH
• 33 mH
• 47 mH
• 82 mH
• 100 mH

Misc

Note: Each piece of equipment listed below requires a DragonCard/Drexel ID to check out.

• Analog Ammeters
• Digital Multimeters
• LCR Meters
• Variable AC Transformer
• Variable AC Voltage Regulator
• 10:1 Step Down Transformers
• OP Amp Boards
• Microsoft Kinect
• Tesla Meter
• Spectrometers
• NI myDAQ
• Resistor Decade Boxes
• Capacitor Decade Boxes
• Inductor Decade Boxes
• Computer Speakers
• Stand-Alone Speakers (8 Ω, 4 W)
• Soldering Equipment
• Other Equipment
